VEVOR Fiber Fusion Splicer, Auto Focus Fiber Optic Fusion Splicer, Fusion Splicer Machine Fiber Cleaver Kit with 5" Digital LCD Screen
Highlights:
1.Faster Splicing & Heating: The fiber fusion splicer with a powerful high-speed motor allows quick 9 second splice time and 30 second heat time. It can continuously splice and heat about 200 times. Thus, it is time-saving in operation.
2.3-in-1 Fiber Holder: It is suitable for SM, MM, bare fiber, pigtail, rubber-insulated, and multi-fiber cables. Applicable Fibers: SM(G.652&G.657); MM(G.651); DS(G.657); NZDS(G.655). It features low splice loss, 0.025dB(SM), 0.01dB(MM), 0.04dB(DS/NZDS). It is fully qualified with FTTH projects, security monitoring, and other fiber cable splicing projects.
3.Clear LCD & 5200 mAh Battery: With 5-inch high-resolution screen, the handheld fiber fusion splicer can get up to 300 times the focus magnifications when X/Y Axis is displayed separately. Due to the 5200 mah battery, the charging time is less than 3 hours.
4.Humanization Tool Kit: The fiber fusion splicer offers excellent accessories, including fiber stripper, AC adapter, lithium battery, spare electrode, charger, cooling tray, operation manual CD, carrying case. The toolbox protects the fiber splicing tools and makes all accessories easy to store and easy to carry.
5.Various Application: Sturdy structures meet different working area requirements, dust-proof, shock-proof, and freeze-proof. The fusion machine is especially suitable for optical fiber and cable projects, maintenance scientific research, electric power, and other communications.
Details:
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
1.Faster Splicing & Heating: The fiber fusion splicer with a powerful high-speed motor allows quick 9 second splice time and 30 second heat time. It can continuously splice and heat about 200 times. Thus, it is time-saving in operation.
2.3-in-1 Fiber Holder: It is suitable for SM, MM, bare fiber, pigtail, rubber-insulated, and multi-fiber cables. Applicable Fibers: SM(G.652&G.657); MM(G.651); DS(G.657); NZDS(G.655). It features low splice loss, 0.025dB(SM), 0.01dB(MM), 0.04dB(DS/NZDS). It is fully qualified with FTTH projects, security monitoring, and other fiber cable splicing projects.
3.Clear LCD & 5200 mAh Battery: With 5-inch high-resolution screen, the handheld fiber fusion splicer can get up to 300 times the focus magnifications when X/Y Axis is displayed separately. Due to the 5200 mah battery, the charging time is less than 3 hours.
4.Humanization Tool Kit: The fiber fusion splicer offers excellent accessories, including fiber stripper, AC adapter, lithium battery, spare electrode, charger, cooling tray, operation manual CD, carrying case. The toolbox protects the fiber splicing tools and makes all accessories easy to store and easy to carry.
5.Various Application: Sturdy structures meet different working area requirements, dust-proof, shock-proof, and freeze-proof. The fusion machine is especially suitable for optical fiber and cable projects, maintenance scientific research, electric power, and other communications.
Details:
JW4108S Fiber Fusion Splicer
This fiber fusion splicer machine is mainly used to connect optical fibers with high-performance and reliable quality, widely applied in cable projects, maintenance scientific research. It features 9 second splice time and 30 second heat time, 200 heating time due to the high-capacity battery. Moreover, it is lightweight and portable.
- Faster Splicing & Heating
- 3-in-1 Fiber Holder
- Clear LCD & 5200 mAh Battery
- Humanization Tool Kit
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
Excellent Splicing Performance
The fiber fusion splicer can complete the whole process of fiber fusion splicing automatically in just 9 seconds, heating in 30 seconds. The high-speed image processing technology unique precision positioning technology is applied while working.
3 in 1 Fiber Holder
SM, MM, bare fiber, pigtail, rubber-insulated, multi fiber cable. Applicable splice machine fibers: SM(0.02db); MM(0.01db); DS(0.04db); NZDS(0.04db). It is fully qualified with FTTH project, security monitoring and other fiber cable splicing projects.
High-Resolution Screen
The fusion splicing machine adopts 5-inch high-resolution LCD screen. The X/Y axis X/Y axis or a separate display shows at the same time, 300/200 times magnification. You can easily and clearly observe the X axis and Y axis direction of the optical fiber.
Dependable Power Supply
5200 mah high-capacity lithium battery features charging time ≤ 3 hours, continuous splicing and heating about 200 times. Built-in power meter and VFL effectively measure connection loss, verify continuity and help assess fiber link transmission quality.
Exquisite Toolbox
Fusion splice machine comes with plenty accessories, fiber stripper, AC adapter, lithium battery, charger, cooling tray, fiber cleaver, carrying strip, and so on. Toolbox keeps it clean and protects it against strong vibrations and shocks.
Wide Application
Fiber fusion is especially suitable for optical fiber and cable projects, maintenance scientific research, and teaching in telecommunications. Radio and television, railway, petrochemical, electric power, military, public security, and other communications fields are also applied.
Specifications
- Model: JW4108S
- Splicing time: ≤9s
- Heating time: ≤30s
- Cleaved Length: 8～16mm
- Fiber Image/ Magnification: 300/200
- Heat shrink bush: 60mm, 40mm and a series of miniature bush
- Power supply: 12V built-in lithium battery
- Battery Capacity: 5200mah
- Charging time: 3h
- External adapter: input AC100-240V50/60HZ, output DC13.5V/4.5A
Package Content
- 1 x Fusion Splicer
- 1 x Fiber Cleaver
- 1 x Power Adapter
- 1 x Miller stripper
- 1 x Kit of Accessories
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
JW4108S Fiber Fusion Splicer
This fiber fusion splicer machine is mainly used to connect optical fibers with high-performance and reliable quality, widely applied in cable projects, maintenance scientific research. It features 9 second splice time and 30 second heat time, 200 heating time due to the high-capacity battery. Moreover, it is lightweight and portable.
- Faster Splicing & Heating
- 3-in-1 Fiber Holder
- Clear LCD & 5200 mAh Battery
- Humanization Tool Kit
Excellent Splicing Performance
The fiber fusion splicer can complete the whole process of fiber fusion splicing automatically in just 9 seconds, heating in 30 seconds. The high-speed image processing technology unique precision positioning technology is applied while working.
3 in 1 Fiber Holder
SM, MM, bare fiber, pigtail, rubber-insulated, multi fiber cable. Applicable splice machine fibers: SM(0.02db); MM(0.01db); DS(0.04db); NZDS(0.04db). It is fully qualified with FTTH project, security monitoring and other fiber cable splicing projects.
High-Resolution Screen
The fusion splicing machine adopts 5-inch high-resolution LCD screen. The X/Y axis X/Y axis or a separate display shows at the same time, 300/200 times magnification. You can easily and clearly observe the X axis and Y axis direction of the optical fiber.
Dependable Power Supply
5200 mah high-capacity lithium battery features charging time ≤ 3 hours, continuous splicing and heating about 200 times. Built-in power meter and VFL effectively measure connection loss, verify continuity and help assess fiber link transmission quality.
Exquisite Toolbox
Fusion splice machine comes with plenty accessories, fiber stripper, AC adapter, lithium battery, charger, cooling tray, fiber cleaver, carrying strip, and so on. Toolbox keeps it clean and protects it against strong vibrations and shocks.
Wide Application
Fiber fusion is especially suitable for optical fiber and cable projects, maintenance scientific research, and teaching in telecommunications. Radio and television, railway, petrochemical, electric power, military, public security, and other communications fields are also applied.
Package Content
- 1 x Fusion Splicer
- 1 x Fiber Cleaver
- 1 x Power Adapter
- 1 x Miller stripper
- 1 x Kit of Accessories
Specifications
- Model: JW4108S
- Splicing time: ≤9s
- Heating time: ≤30s
- Cleaved Length: 8～16mm
- Fiber Image/ Magnification: 300/200
